Glass Flake Liquid Automatic Water Sandblasting Machine

 MAGIN760-36A assembly line automatic liquid sandblasting line-Mobile phone monitor lens sandblasting machine, glass lens sandblasting machine, rearview mirror glass lens sandblasting machine, each Touch screen lens sandblasting machine, mobile phone display glass lens, mobile phone back cover ceramic / glass special through-type automatic liquid sandblasting line,

   The high-end liquid automatic water sandblasting machine produced by Dongguan Meijun Automation Equipment Co., Ltd. has been applied to the top mobile phone parts manufacturers for the production of the latest international mainstream high-end mobile phone glass lenses, ceramic shells, and glass shells.

MAGIN760-36A line automatic liquid sandblasting line-suitable for display glass sandblasting, mobile phone back cover ceramic/ span>Glass blasting, automotive rearview mirror glass blasting process.

This device has several sophisticated features:

1)    Superfine powder abrasive smooth blasting function;

2)    Powder uniform atomization and water fusion function;

3)    The trough integrated abrasive fluid fusion uniform function;

4)    Quickly activate the anti-sedimentation function to ensure a longer service life of the equipment;

5)    Sandblasting is uniform, the mirror surface is uniform after spraying, and the same color;

The working process of this machine is module loading, sandblasting-1 cleaning-sand blasting-2cleans-sandblasting-3cleans< span lang="EN-US">-blasting-4cleaning-baking Dry - the next piece.

With automatic separation and automatic cleaning of water and sand, it can clean and dry all the sand on the workpiece without leaving water droplets on the workpiece.

    The working method of the machine: after the workpiece enters the conveying line body, the conveying line brings the workpiece to the sandblasting processing position, and the sandblasting nozzle transports reciprocating swing (adjustable speed) to blast clean the surface of the workpiece , After sandblasting, the workpiece continues to run to the washing chamber, and the washing water is automatically sprinkled to wash the outer surface of the workpiece. The cleaned workpiece enters the next sandblasting chamber for sandblasting and cleaning, and circulates several times to reach the standard. Please take care of the surface cleaning, and finally the workpiece enters the next process.
    Workflow:
    Workpiece blasting process

    1. Connect the power supply and the compressed air source;
    2. Adjust various parameters;

    4. Start the water mist fan motor; (high-end models do not need to pump water mist)
    5. Feeding;
    6, open the automatic processing button;
    7 、The workpiece automatically enters the sandblasting area;
    8. Automatic sandblasting;
    9, automatic flushing spray;
    10. Air knife blowing;
    11、Processing cycle
   The high-end liquid automatic water sandblasting machine produced by Dongguan Meijun Automation Equipment Co., Ltd. has been applied to the top mobile phone parts manufacturers for the production of international mainstream high-end mobile phone glass lenses, ceramic shells, and glass shells.
