    Ultra-high pressure water sandblasting machine 500 kg environmental protection rust and paint removal equipment

    Meijun sandblasting machine (high-pressure water sandblasting machine) can be used in a variety of ways and can be used for two purposes: one is simple pressure water cleaning, high-pressure water flow can clean some relatively firm dirt such as cement, bark, road surface some dirt, etc. 2. It is a new type of equipment for surface cleaning by spraying some sand materials through high-speed adsorption, that is, water sandblasting - rust removal, paint removal, and oxide removal.

    With the rapid development of my country's modern industry, more and more new technology equipment has been widely used, some traditional process equipment is gradually being replaced by new equipment, high-pressure water jet sandblasting machine is one of the more typical equipment.

    High pressure water blasting machine (500kg pressure) can be used in: oil tank derusting and renovation, ship oxide layer cleaning, steel plate surface corrosion cleaning, cement equipment and Cleaning of cement plants, high pressure washing of roads, bark peeling without damage, rust treatment of oxide layer on the surface of pipelines, anti-corrosion renovation of bridges, paint removal and renovation of automobile surfaces, thick paint cleaning of tanks, engineering outdoor surface treatment and other facilities.

    High pressure water sand blasting machine, shot blasting machine, sand blasting room, sand blasting wear-resistant material and related sand blasting machine accessories Production and manufacturing. With high domestic level, and with its high efficiency, reliability and stable performance, it has won the praise of the majority of users, The products are exported to Hong Kong, Taiwan, Southeast Asia and Europe and the United States.

    1. Meijun Sandblasting Equipment 500 Details of High Pressure Water Sandblasting Machine

    ·                        Brand: Meijunmagin

    ·                        Model:MJGS500

    ·                        Moving method: wheel dragging

    ·                        Drive engine: motor drive

    ·                        Usage:Industrial

    ·                        Outlet water temperature:40Liquid below degrees

    ·                        Processing customization: yes

    ·                        Work pressure:350bar

    ·                        Workflow:1250L/min

    ·                        High pressure tube length:10-20m

    ·                        Power:380V50Hz

    ·                        Power:3.5kW

    ·                        Water pipe dimensions:28*16mm

    ·                        Weight:230kg

    ·                        Power consumption:12KW

    ·                        Speed:1550RPM

    ·                        Size:1200*650*860mm

    Gun diameter:2-6mm

    1.High-precision crankshaft pump, 2.Three ceramic plungers and brass pump heads,3.TSI intelligent control,4.Pressure regulator/safety valve,5.Bypass stainless steel water tank,6.Automatic switch handle,7.Pressure gauge,8.Automatic shutdown,9.Motor thermal protection,10.The coupling connects the pump and the motor,11.Heavy duty tires,12.Stainless steel shell/reinforced steel structure,13.10 meters high pressure hose,14.25 degree high pressure nozzle,15.heavy duty gun

    Second, Meijun Magin Technical parameters of water sandblasting machine

    Power Supply Phase/Volt/Hertz:3/380/50

    Pressure bar/MPa:500/50

    Inlet water temperature Celsius:60

    Connection Power kw:22

    RPM RPM:1550

    Machine Weight:250

    Dimensions(L*W*H mm):1200*650*860mm

    3.Product application Meijun Magin High pressure water descaling machine

    1.Cleaning of rotary cellar and equipment in cement plant

    2.Concrete cleaning and roughening of construction sites Surface coating removal.

    3.Surface cleaning of large transport vehicles and internal cleaning during maintenance.

    4.Non-destructive sand cleaning on the casting surface

    four, standard configuration

    Industrial Crankshaft Pump Head and Oil Window

    Stepless pressure regulating valve

    4 kinds of high-pressure powerful nozzles

    Leakage protection device

    15 meters high pressure pipe

    Industrial high pressure spray gun

    V. Application of high pressure cleaning machine sand blasting device High pressure wet sand blasting technology:

    The high-pressure water sandblasting device is a device that combines the two technologies of water and sand. It combines the advantages of the two technologies and has a unique effect of removing paint and rust.

    The working principle of the sandblasting device of the high-pressure cleaning machine is to use the negative pressure adsorption of the high-pressure water jet, adopt the post-mixing method, add solid particles of appropriate labels to the high-pressure water jet, and use the wedge-shaped peeling, jet impact, shearing and shearing of the solid-liquid mixed fluid. Cut and other composite damage, remove the paint layer or other covering attached to the surface of the substrate.

    Industrial grade ultra-high pressure liquid cleaning machine, the cleaning pressure is up to 500 kg and the flow rate is 20 liters/min. It uses advanced ceramic plungers, high-pressure water pumps and multi-layer industrial-grade seals. Difficult industrial cleaning and rust removal, can be used for oil tanks, heat exchangers, cement plant preheating chamber crust, steel surface paint, pipeline dredging, casting rust removal, widely used in paper mills, chemical plants, automobile manufacturers, shipyards, railroads , Petroleum Heavy Industry, etc.

    Features of this level: no compressed air, only high pressure water pump

    Our products have been applied to Heyuan Power Plant Humen Power Plant Shaoguan Power Plant Zhuhai Gaolan Port Zhuhai Wharf Natural Gas Engineering,CCCC Fourth Navigation Bureau Jiufeng Steel Structure ENN Gas Xinyi Glass CSG Glass Wuchang Shipyard CSR Group Sany Heavy Industry and other civil and processing enterprises
